STEEL SHEETS
We offer steel sheets in different gauges from 22 to 3/16 ”and sizes from 3×8 to 4×10.
Useful for any metal worker job.
Description | Width (ft) | Length (ft) | Width (m) | Length(m) | Sheet type | Gauge (nominal) | Thickness | Kg / m | Pieces / bundle | Kg / bundle |
|---|---|---|---|---|---|---|---|---|---|---|
L 3x8 | 3 | 8 | 0.91 | 2.44 |
| 20 | 0.0359" | 15.95 | 95 | 1,516 |
18 | 0.0478" | 21.78 | 75 | 1,633 |
||||||
16 | 0.0598" | 26.57 | 60 | 1,594 |
||||||
|
| 0.0598" | 26.57 | 60 | 1,594 |
|||||
14 | 0.0747" | 34.66 | 50 | 1,733 |
||||||
L 3x10 | 3 | 10 | 0.91 | 3.05 |
| 24 | 0.0239" | 13.28 | 120 | 1,593 |
22 | 0.0299" | 16.61 | 95 | 1,578 |
||||||
20 | 0.0359" | 19.94 | 80 | 1,595 |
||||||
18 | 0.0478" | 27.22 | 60 | 1,633 |
||||||
16 | 0.0598" | 33.22 | 50 | 1,661 |
||||||
| 16 | 0.0598" | 33.22 | 50 | 1,661 |
|||||
14 | 0.0747" | 43.33 | 40 | 1,733 |
||||||
12 | 0.1046" | 60.55 | 30 | 1,816 |
||||||
11 | 0.1196" | 69.23 | 22 | 1,523 |
||||||
10 | 0.1345" | 80.50 | 20 | 1,610 |
||||||
3/16" | 0.1875" | 104.42 | 15 | 1,566 |
||||||
L 4x8 | 4 | 8 | 1.22 | 2.44 |
| 20 | 0.0359" | 21.27 | 75 | 1,595 |
18 | 0.0478" | 29.03 | 55 | 1,597 |
||||||
16 | 0.0598" | 36.31 | 45 | 1,634 |
||||||
| 16 | 0.0598" | 36.31 | 45 | 1,634 |
|||||
14 | 0.0747" | 46.22 | 40 | 1,849 |
||||||
11 | 0.1196" | 70.81 | 22 | 1,558 |
||||||
3/16" | 0.1875" | 115.76 | 15 | 1,736 |
||||||
L 4x10 | 4 | 10 | 1.22 | 3.05 |
| 22 | 0.0299" | 22.15 | 70 | 1,550 |
20 | 0.0359" | 26.59 | 60 | 1,595 |
||||||
18 | 0.0478" | 35.43 | 40 | 1,417 |
||||||
16 | 0.0598" | 44.29 | 40 | 1,772 |
||||||
| 16 | 0.0598" | 44.29 | 40 | 1,772 |
|||||
14 | 0.0747" | 57.77 | 30 | 1,733 |
||||||
12 | 0.1046" | 80.73 | 20 | 1,615 |
||||||
11 | 0.1196" | 88.58 | 20 | 1,772 |
||||||
10 | 0.1345" | 99.62 | 16 | 1,594 |
||||||
3/16" | 0.1875" | 144.70 | 11 | 1,592 |
||||||
1/4" | 0.2500" | 192.93 | 10 | 1,929 |
| Cold Rolled |
| Hot Rolled |
